Description

YKHMI PLC Controller

Name: YKHMI MM-30MT-4MT-430-FX-A PLC Controller with 4.3-inch HMI
Brand: SaleCNC
Price: 137.25 USD
Availability: InStock

controller PLC YKHMI 1 1 controller PLC YKHMI 2 1

controller PLC YKHMI 1 controller PLC YKHMI 2

controller PLC YKHMI 3 controller PLC YKHMI 4

controller PLC YKHMI

No.	Example	Detail
1	MM	PLC Touch Screen Size	MM: Millimeters CM: Centimeters
2	30MT	Digital Inputs and Relay Outputs	20: 12 IN / 8 OUT 24: 15 IN / 12 OUT 30: 16 IN / 14 OUT 40: 24 IN / 16 OUT
3	4MT	Transistor Outputs
4	700	Touch Screen Size	430: 4.3 inches (480×272) 450: 4.5 inches (480×272) 500: 5.0 inches (480×272) 700: 7.0 inches (800×480) 1000: 10.1 inches (1024×600)
5	FX	PLC Programming Software Compatibility	FX: Compatible with Mitsubishi FX1S, FX1N (GX Developer) ES: Compatible with Delta PLC (WPLSOFT ES2)
6	B	Configuration	A: Standard Model, No Analog Ports B: Analog Input/Output and NTC 10K B value 3435. C: Analog Input/Output, K-Type Thermocouple. D: Analog Input/Output, NTC 10K B value 3435, RS485. E: Analog Input/Output, K-Type Thermocouple, RS485. F: Analog Input/Output and PT100 (ALPHA value = 0.00385).

Model	PLC YKHMI 4.3 inch	PLC YKHMI 5 inch	PLC YKHMI 7 inch	PLC YKHMI 10 inch
Dimensions	138x86x44.5 mm	180x104x52.7 mm	204x150x50.9 mm	280x193x51 mm
Panel Cutout Size	131×80 mm	154×94 mm	192×138 mm	262×181 mm
Screen Size	4.2″ TFT	5.0″ TFT	7.0″ TFT	10.0″ TFT
Display Area	111×63 mm	111×63 mm	155×86 mm	222×125 mm
Digital Inputs	12 channels (NPN type)	12 channels (NPN type)	24 channels (NPN type)	36 channels (NPN type)
Digital Outputs	6 Transistor, 8 Relay	12 Transistor, 8 Relay	4 Transistor, 16 Relay	12 Transistor, 16 Relay
Analog Inputs	4 channels	2 channels	4 channels	0
Analog Outputs	2 channels	2 channels	2 channels	0
Temperature Inputs	2 channels (B value 3435, 10K NTC thermistor)	2 channels (B value 3435, 10K NTC thermistor)	2 channels (B value 3435, 10K NTC thermistor)	0
Power Supply	24V DC / 3A
