Description

Conveyor Belt 201 Mesh

Stainless Steel 201 Mesh Conveyor Belt

Stainless Steel 201 Frame (Non-Adjustable Height Legs)

• Mesh type conveyor belt for material handling and transport.
• Equipped with an electric motor for adjustable flow speed.
• Facilitates easy material transfer and organization; simple installation and operation.
• Standard machine height: 75 cm (non-adjustable).
• Product on conveyor about 40kg
• Temperature resistant from -50 to +200 degrees Celsius.

Mesh Belts are a type of conveyor belt constructed from interconnected wires or fibers forming a mesh pattern. This design allows for easy passage of air or liquids. These belts are commonly used in applications requiring ventilation or cooling, as well as for material transport across various industries, particularly in baking and heating processes.

Mesh Belt Features and Applications:

1. Excellent Ventilation: The mesh structure provides air gaps between the wires, enhancing ventilation and heat dissipation efficiency.
2. High-Temperature Resistance: Mesh belts are often employed in processes involving baking or heating, such as drying food products or curing materials.
3. Diverse Material Options: Mesh belts can be manufactured from various materials, including stainless steel, plated steel, or corrosion-resistant alloys.
4. Industrial Applications: Frequently utilized in the food industry (for drying or baking), chemical processing, component manufacturing, and assembly lines that require airflow.

Product examples:

Inverter Motor Motor Speed Ratio 30-40 meters/minute, additional cost 7500 Baht

• Conveyor Belt PVC 500x1000x750 mm
• Speed 40 m/min, 100 mm adjustable leg height.
• Load capacity: 3 Kg. across the entire belt.
• Price: 32,000 Baht

• Conveyor Belt PVC 500x1500x750 mm
• Speed 40 m/min, 100 mm adjustable leg height.
• Load capacity: 3 Kg. across the entire belt.

• Conveyor Belt PU with Stainless Steel Frame, 400x1500x800 mm
• Speed 8-13 m/min, 100 mm adjustable leg height.
• Load capacity: 30 Kg. across the entire belt.

• Conveyor Belt PVC with Aluminum Profile Frame, 300×1500 mm
• Speed 8-13 m/min, adjustable legs.
• Load capacity: 20 Kg. across the entire belt.

• Conveyor Belt PU with Aluminum Profile Frame, 500×4500 mm
• Speed 8-13 m/min, adjustable legs.
• Load capacity: 30 Kg. across the entire belt.

• Conveyor Belt PVC with Aluminum Profile Frame, 300×6000 mm
• Speed 8-13 m/min, adjustable legs.
• Load capacity: 30 Kg. across the entire belt.

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table, 500×3000 mm
• Speed 3-5 m/min, adjustable legs.
• Load capacity: 30 Kg. across the entire belt.

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table, 400×3000 mm
• Speed 3-5 m/min, adjustable legs.
• Load capacity: 30 Kg. across the entire belt.

• Conveyor Belt PU with Stainless Steel 304 Frame, 500×1500 mm
• Speed 8-13 m/min, adjustable legs.
• Load capacity: 30 Kg. across the entire belt.

• Steel Structure Stainless 304 Conveyor Solid

• Speed 3-5 m/min, adjustable legs.
• Load capacity: 40 Kg. across the entire belt.

• Conveyor Belt PVC 300x1500x750 mm
• Conveyor Belt PVC 300x1000x750 mm
• Conveyor Belt PVC 300x1200x300 mm
• Speed 8-13 m/min
• Weight: 2-3 kg.

•
• Conveyor Belt PVC with Aluminum Profile Frame, 300×1500 mm
• Speed 8-13 m/min, adjustable legs.
• Load capacity: 30 Kg. across the entire belt.

• Stainless Steel 304 Mesh Conveyor with Stainless Steel 304 Frame, 600×1000 mm
• Speed 3-5 m/min, adjustable legs.
• Load capacity: 40 Kg. across the entire belt.

Conveyor Belt PVC Speed Specifications

**England**

**Thai Language**

Product on conveyor about 30kg

• Normal motor is 120W, Option: 200W, 400W, 600W

Differences between PVC, PU, and Stainless Steel Conveyor Belts

1. Materials and Properties

   • PVC (Polyvinyl Chloride)
     ✅ Flexible and offers moderate chemical resistance.
     ✅ More economical than PU and stainless steel.
     ✅ Suitable for general applications such as packaging or transporting materials without oil or grease.
     ❌ Not resistant to high temperatures and may wear faster than PU.

   • PU (Polyurethane)
     ✅ Superior resistance to grease, oil, and chemicals compared to PVC.
     ✅ Smoother surface, ideal for food and pharmaceutical industries.
     ✅ More resistant to tearing and offers a longer service life than PVC.
     ❌ Higher cost than PVC.

   • Stainless Steel
     ✅ High strength, resistant to impact and abrasion.
     ✅ Suitable for industries requiring high hygiene standards, such as food and beverage processing.
     ✅ Resistant to high temperatures and chemicals.
     ❌ Higher cost and potentially heavier.

2. Recommended Applications

   • PVC → General goods transport, such as packaging and electronics.
   • PU → Food, pharmaceutical industries, and applications involving contact with oil or grease.
   • Stainless Steel → Applications demanding high cleanliness or operating in high-temperature or high-humidity environments, such as food and beverage production facilities and heavy industry.
