Description

Stainless 304 Conveyor

This Stainless Steel 304 Conveyor features a flat belt design and a robust Steel Structure. The frame is fixed in height and does not offer adjustable legs.

• Mesh belt conveyor for material handling and transport.
• Equipped with an electric motor for adjustable speed control.
• Facilitates easy material transport and item collation; simple to install and operate.
• Standard machine height: 75 cm (non-adjustable).
• Product load capacity on conveyor: Approximately 40 kg.
• Temperature resistance: -50 to +200 degrees Celsius.

Mesh Belt conveyors utilize a belt constructed from interconnected wires or fibers forming a mesh pattern, allowing for easy airflow or liquid passage. This type of belt is commonly used in applications requiring ventilation or cooling, as well as for material transport across various industries, particularly in baking or heating processes.

Mesh Belt Features and Applications:

1. Excellent Ventilation: The mesh structure provides gaps between wires, ensuring efficient airflow and heat dissipation.
2. High-Temperature Resistance: Mesh belts are ideal for processes involving baking or heating, such as food drying or material baking.
3. Diverse Material Construction: Mesh belts can be manufactured from various materials, including stainless steel, plated steel, or corrosion-resistant alloys.
4. Industrial Applications: Frequently employed in the food industry (drying/baking), chemical processing, component manufacturing, and assembly lines requiring air circulation.

Example Products:

Inverter Motor: Speed ratio 30-40 meters/minute. Add-on cost: 7500 THB.

• Conveyor Belt PVC: 500x1000x750 mm
• Speed: 40 m/min; Adjustable leg height: 100 mm.
• Total belt load capacity: 3 kg.
• Price: 32,000 THB.

• Conveyor Belt PVC: 500x1500x750 mm
• Speed: 40 m/min; Adjustable leg height: 100 mm.
• Total belt load capacity: 3 kg.

• Conveyor Belt PU with Stainless Steel Frame: 400x1500x800 mm
• Speed: 8-13 m/min; Adjustable leg height: 100 mm.
• Total belt load capacity: 30 kg.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min; Adjustable legs.
• Total belt load capacity: 20 kg.

• Conveyor Belt PU with Aluminum Profile Frame: 500×4500 mm
• Speed: 8-13 m/min; Adjustable legs.
• Total belt load capacity: 30 kg.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×6000 mm
• Speed: 8-13 m/min; Adjustable legs.
• Total belt load capacity: 30 kg.

• Conveyor Belt PU with Stainless Steel 304 Frame and Stainless Steel 304 Table: 500×3000 mm
• Speed: 3-5 m/min; Adjustable legs.
• Total belt load capacity: 30 kg.

• Conveyor Belt PU with Stainless Steel 304 Frame and Stainless Steel 304 Table: 400×3000 mm
• Speed: 3-5 m/min; Adjustable legs.
• Total belt load capacity: 30 kg.

• Conveyor Belt PU with Stainless Steel 304 Frame: 500×1500 mm
• Speed: 8-13 m/min; Adjustable legs.
• Total belt load capacity: 30 kg.

• Conveyor Belt Stainless Steel 304 with Steel Frame
• Speed: 3-5 m/min; Adjustable legs.
• Total belt load capacity: 30 kg.

• Conveyor Belt PVC: 300x1500x750 mm
• Conveyor Belt PVC: 300x1000x750 mm
• Conveyor Belt PVC: 300x1200x300 mm
• Speed: 8-13 m/min
• Weight capacity: 2-3 kg.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min; Adjustable legs.
• Total belt load capacity: 30 kg.

• Stainless Steel 304 Mesh Conveyor with Stainless Steel 304 Frame: 600×1000 mm
• Speed: 3-5 m/min; Adjustable legs.
• Total belt load capacity: 40 kg.

• Stainless Steel 304 Conveyor with Steel Structure
• Speed: 3-5 m/min; Height: 750 mm.
• Total belt load capacity: 40 kg.

Conveyor Belt PVC Speed Specifications

England

Thai

https://youtu.be/nlWc4jRPjM0?si=pLIe53J2EObnbE1w

Product load capacity on conveyor: Approximately 30 kg.

• Standard motor: 120W. Optional motors available: 200W, 400W, 600W.

Differences between PVC, PU, and Stainless Steel Conveyor Belts

1. Materials and Properties

   • PVC (Polyvinyl Chloride)
     ✅ Flexible and offers moderate chemical resistance.
     ✅ More economical than PU and stainless steel.
     ✅ Suitable for general applications such as packaging or material transport of non-oily/greasy substances.
     ❌ Not resistant to high temperatures; may show accelerated wear compared to PU.
   • PU (Polyurethane)
     ✅ Superior resistance to oils, fats, and chemicals compared to PVC.
     ✅ Smoother surface finish, ideal for food and pharmaceutical industries.
     ✅ Higher tensile strength and longer service life than PVC.
     ❌ Higher cost than PVC.
   • Stainless Steel
     ✅ High mechanical strength, resistant to impact and abrasion.
     ✅ Suitable for industries requiring high hygiene standards, such as food and beverage production.
     ✅ Resistant to high temperatures and chemicals.
     ❌ Higher cost and potentially heavier weight.

2. Recommended Applications

   • PVC → General cargo transport, e.g., packaging, electronics.
   • PU → Food and pharmaceutical industries, applications involving contact with oil or fat.
   • Stainless Steel → Applications demanding stringent hygiene or harsh environments (high heat/humidity), such as food and beverage processing plants, and heavy industrial sectors.
