Conveyor Belt PVC

Conveyor Belt – PVC Type

Stainless Steel 201 Frame (Non-adjustable Height Legs)

Polyvinylchloride (PVC)

• PVC offers excellent resistance to high temperatures, tensile strength, and puncture resistance.
• PVC exhibits good wear resistance.
• PVC is resistant to oils and odors.
• PVC provides robust durability against abrasion.

Sample Products:

Inverter Motor Motor Speed Ratio 30-40 meters/minute. Additional Charge: 7,500 THB

• Conveyor Belt PVC 500x1000x750 mm
• Speed 40 m/min. Legs with adjustable feet: 100 mm.
• Load Capacity: 3 Kg. total on belt
• Price: 32,000 THB

• Conveyor Belt PVC 500x1500x750 mm
• Speed 40 m/min. Legs with adjustable feet: 100 mm.
• Load Capacity: 3 Kg. total on belt

• Conveyor Belt PU with Stainless Steel Frame: 400x1500x800 mm
• Speed 8-13 m/min. Legs with adjustable feet: 100 mm.
• Load Capacity: 30 Kg. total on belt

• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed 8-13 m/min. Adjustable Legs.
• Load Capacity: 20 Kg. total on belt

• Conveyor Belt PU with Aluminum Profile Frame: 500×4500 mm
• Speed 8-13 m/min. Adjustable Legs.
• Load Capacity: 30 Kg. total on belt

• Conveyor Belt PVC with Aluminum Profile Frame: 300×6000 mm
• Speed 8-13 m/min. Adjustable Legs.
• Load Capacity: 30 Kg. total on belt

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table: 500×3000 mm
• Speed 3-5 m/min. Adjustable Legs.
• Load Capacity: 30 Kg. total on belt

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table: 400×3000 mm
• Speed 3-5 m/min. Adjustable Legs.
• Load Capacity: 30 Kg. total on belt

• Conveyor Belt PU with Stainless Steel 304 Frame: 500×1500 mm
• Speed 8-13 m/min. Adjustable Legs.
• Load Capacity: 30 Kg. total on belt

• Steel Structure Stainless 304 Conveyor Solid

• Speed 3-5 m/min. Adjustable Legs.
• Load Capacity: 40 Kg. total on belt

• Conveyor Belt PVC 300x1500x750 mm
• Conveyor Belt PVC 300x1000x750 mm
• Conveyor Belt PVC 300x1200x300 mm
• Speed 8-13 m/min
• Weight Capacity: 2-3 Kg. total on belt

•
• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed 8-13 m/min. Adjustable Legs.
• Load Capacity: 30 Kg. total on belt

• Stainless Steel Mesh Conveyor with Stainless Steel 304 Frame: 600×1000 mm
• Speed 3-5 m/min. Adjustable Legs.
• Load Capacity: 40 Kg. total on belt

Conveyor Belt PVC Speed Specifications

Product on conveyor about 30kg

• Normal motor is 120W, Option: 200W, 400W, 600W

Differences Between PVC, PU, and Stainless Steel Conveyor Belts

1. Materials and Properties

   • PVC (Polyvinyl Chloride)
     ✅ Flexible and offers moderate chemical resistance.
     ✅ More economical than PU and Stainless Steel.
     ✅ Suitable for general applications such as packaging or transporting materials without oil and grease.
     ❌ Not resistant to high heat and may wear faster than PU.

   • PU (Polyurethane)
     ✅ Superior resistance to fats, oils, and chemicals compared to PVC.
     ✅ Smoother surface, ideal for food and pharmaceutical industries.
     ✅ Higher tear resistance and longer service life than PVC.
     ❌ Higher cost than PVC.

   • Stainless Steel
     ✅ High strength, resistant to impact and abrasion.
     ✅ Suitable for industries requiring high hygiene standards, such as food and beverage.
     ✅ Resistant to high temperatures and chemicals.
     ❌ High cost and potentially heavy.

2. Recommended Applications

   • PVC → Used for general material handling, e.g., packaging, electronics.
   • PU → Used in food, pharmaceutical industries, and applications involving contact with oil or grease.
   • Stainless Steel → Used in applications requiring high cleanliness or in environments with high temperatures or humidity, such as food and beverage processing plants, and heavy industries.
