Description

Conveyor Belt PU

Frame Construction: Stainless Steel 304 (Non-adjustable feet)

• Type: Polyurethane (PU) conveyor belt for material handling and transport.
• Equipped with an electric motor allowing for adjustable belt speed.
• Facilitates easy material transfer and organization; simple installation and operation.
• Standard height: 75 cm (non-adjustable).
• Load capacity: Approximately 30 kg per meter of conveyor.

Polyurethane (PU) Belt Properties:

1. High Durability: Exhibits excellent strength and wear resistance, suitable for heavy-duty applications.
2. Chemical Resistance: Resists various chemicals, including certain acids and alkalis, making it ideal for chemical processing environments.
3. High-Temperature Tolerance: Can withstand higher temperatures compared to many other belt materials.
4. Flexibility and Customization: Highly flexible, allowing for tailored shapes and sizes. Can be designed for enhanced grip or flexibility.
5. Scratch Resistance: Offers good resistance to abrasion, suitable for contact with rough or abrasive materials.
6. Lightweight: Lighter than many alternative belt materials, simplifying installation and reducing operational resistance.
7. Tensile Strength: Possesses high tensile and compressive strength for robust material transport systems.
8. Quiet Operation: Operates with minimal noise, contributing to a quieter manufacturing environment.

With these properties, PU belts are well-suited for industries such as food processing, automotive manufacturing, and general factory material handling.

Example Product Configurations:

Motor with Inverter for Speed Adjustment 30-40 meters/minute, add 7500 Baht

• Conveyor Belt PVC 500x1000x750 mm
• Speed: 40 m/min, with adjustable 100 mm feet.
• Load Capacity: 3 kg across the belt.
• Price: 32,000 Baht

• Conveyor Belt PVC 500x1500x750 mm
• Speed: 40 m/min, with adjustable 100 mm feet.
• Load Capacity: 3 kg across the belt.

• Conveyor Belt PU, Stainless Steel Frame: 400x1500x800 mm
• Speed: 8-13 m/min, with adjustable 100 mm feet.
• Load Capacity: 30 kg across the belt.

• Conveyor Belt PVC, Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min, with adjustable feet.
• Load Capacity: 20 kg across the belt.

• Conveyor Belt PU, Aluminum Profile Frame: 500×4500 mm
• Speed: 8-13 m/min, with adjustable feet.
• Load Capacity: 30 kg across the belt.

• Conveyor Belt PVC, Aluminum Profile Frame: 300×6000 mm
• Speed: 8-13 m/min, with adjustable feet.
• Load Capacity: 30 kg across the belt.

• Conveyor Belt PU, Stainless Steel 304 Frame with Stainless Steel 304 Table: 500×3000 mm
• Speed: 3-5 m/min, with adjustable feet.
• Load Capacity: 30 kg across the belt.

• Conveyor Belt PU, Stainless Steel 304 Frame with Stainless Steel 304 Table: 400×3000 mm
• Speed: 3-5 m/min, with adjustable feet.
• Load Capacity: 30 kg across the belt.

• Conveyor Belt PU, Stainless Steel 304 Frame: 500×1500 mm
• Speed: 8-13 m/min, with adjustable feet.
• Load Capacity: 30 kg across the belt.

• Steel Structure: Stainless Steel 304 Conveyor, Solid Type
• Speed: 3-5 m/min, with adjustable feet.
• Load Capacity: 40 kg across the belt.

• Conveyor Belt PVC 300x1500x750 mm
• Conveyor Belt PVC 300x1000x750 mm
• Conveyor Belt PVC 300x1200x300 mm
• Speed: 8-13 m/min
• Weight: 2-3 kg.

•
• Conveyor Belt PVC, Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min, with adjustable feet.
• Load Capacity: 30 kg across the belt.

• Conveyor Belt (Stainless Mesh), Stainless Steel 304 Frame: 600×1000 mm
• Speed: 3-5 m/min, with adjustable feet.
• Load Capacity: 40 kg across the belt.

Conveyor Belt PVC Speed Specifications

English

Thai

Product load capacity approximately 30 kg.

• Standard motor: 120W. Optional motors available: 200W, 400W, 600W.

Comparison of PVC, PU, and Stainless Steel Conveyor Belts

1. Materials and Properties

   • PVC (Polyvinyl Chloride)
     ✅ Moderate flexibility and chemical resistance.
     ✅ Lower cost compared to PU and stainless steel.
     ✅ Suitable for general applications such as packaging or conveying non-oily/fatty materials.
     ❌ Less resistant to high temperatures and may wear faster than PU.
   • PU (Polyurethane)
     ✅ Superior resistance to oils, fats, and chemicals compared to PVC.
     ✅ Smoother surface finish, suitable for food and pharmaceutical industries.
     ✅ Higher tear resistance and longer service life than PVC.
     ❌ Higher cost than PVC.
   • Stainless Steel
     ✅ High strength, resistant to impact and abrasion.
     ✅ Suitable for industries requiring high hygiene standards, such as food and beverage production.
     ✅ Resistant to high temperatures and chemicals.
     ❌ High cost and potentially heavier weight.

2. Recommended Applications

   • PVC → General cargo transport (e.g., packaging, electronics).
   • PU → Food, pharmaceutical, and applications involving contact with oils or fats.
   • Stainless Steel → High-hygiene applications or environments with high temperatures or humidity (e.g., food and beverage processing, heavy industries).
