MZF-20C 20W Fiber Laser Engraver

Original price was: ฿145,000.Current price is: ฿89,990.

backBack to CNC Laser
SKU: fiber-marking-20w Category:

Description

MZF-20C 20W Fiber Laser Engraver

The MZF-20C utilizes fiber laser technology for durable marking and engraving. With an operational lifespan of up to 100,000 hours, it is capable of marking and engraving characters and designs on a wide range of materials including steel, aluminum, stainless steel, plastics, and acrylics. It is not suitable for transparent materials such as clear acrylic or glass. This unit includes a 1-year warranty on electronics and licensed software.

Fiber

This engraving machine supports Windows 7, 10, and XP (64/32-bit) operating systems and utilizes the EZcad software for design. It supports common vector file formats including *.ai, *.dxf, *.plt, *.dst, *.svg, *.nc, and *.g.

  • Engraving Area: 100×100 mm
  • Engraving Depth: Minimum 2 mm; Maximum 0.01 mm
  • Engraving Speed: 1 second per 800 characters (1mm character size)
  • Integrated cooling system for continuous operation.


1
2

Ring Engraving with 20W Fiber Laser Engraver + Rotary Module


spc laser engrave 20W
Windows10
Fiber engraving2300x400
Fiber engraving3300x400
Fiber engraving3400x400
Fiber

Optional Add-ons

Rotary Unit – enables cylindrical marking

D80 100

Rotary Device Options

  • D80 – 80mm Nema34 motor, adjustable angle. Additional cost: 39,000 THB.
  • D100 – 100mm Nema34 motor, adjustable angle. Additional cost: 45,000 THB.



Video Demonstration available. An alternative configuration includes an industrial computer.

https://salecnc.net/product/cnc-marking-laser



Assembly Video

Easy Operation Guide for Fiber Laser 20W

Setup and Use Tutorial: Laser 20W

Laser Rotary Marking:


Engraving QR Codes

Engraving Pens

Picture3 Picture4

Machine Specifications:

Fiberlasermarking20W

Fiber Marking Machine 20W Parameters

Material Marking Effect Depth (mm) Speed (mm/s) Power (%) Frequency (kHz)
Aluminum Oxide block Dark Mark 0.01 300 50 250
Stainless Steel block White Mark 0.01 100 40 80
Stainless Steel block Dark Mark 0.05 1000 65 35
Foreign White Copper Sheet White Mark 0.03 1000 100 50
Stainless Steel block Deep Mark, Dark Mark 0.05 500 80 20
Stainless Steel block Deep Mark, Dark Mark 0.01 200 40 80
Stainless Steel block Deep Mark, Dark Mark 0.01 200 40 80
Stainless Steel block Dark Mark 0.01 200 40 80
Stainless Steel block Dark Mark 0.01 220 40 80
White Lampshade Dark Mark 0.03 1200 90 25
Red Button White Mark 0.01 1300 65 35
White & Black Lacquer Buttons White Mark 0.04 1000 65 35
Silver Material White Mark 0.05 1200 100 35
Stainless Steel block Wire Drawing 0.09 1000 70 35
Stainless Steel block Wire Drawing 0.12 1000 70 35
Stainless Steel block Wire Drawing 0.25 1000 70 35
Red Copper Deep Mark, White Mark 0.02 100 100 20
Red Copper Deep Mark, White Mark 0.02 1000 70 80
Red Copper Deep Mark, Red Mark 0.01 100 100 80
Red Copper Deep Mark, Red Mark 0.03 1200 65 25
White Plastic Pipes Black Mark 0.03 1200 65 25
White Background Coating Blue Lacquer White Mark 0.03 800 85 40
Circuit Board White Mark 0.01 1000 95 32
Aluminum Molds White Mark 0.05 100 95 45
Brass White Mark 0.05 1000 80 40
Black Hard Plastic White Mark 0.05 1500-2000 60-75 25-45
Iron White Mark 0.05 1000 55 35
New Laser Housing Dark Mark 0.01 100 100 20
Brass Deep Mark, Dark Mark 0.01 100 95 20
Aluminum Alloy Deep Mark, Dark Mark 0.01 200 100 30



Sample Workpieces:

Engraved brand logos and product models.
ALC32 1 ALC32 3

11.CNC%20Marking%20Laser%20Optical%2010W%20Machine

494840 494838

494839


Download the EZCAD software manual here: Click for Manual

EZCad Software Installation Guide for salecnc.net 20W Fiber Laser Engraver

EZCad Software Usage Guide for salecnc.net 20W Fiber Laser Engraver Part 1

EZCad Software Usage Guide for salecnc.net 20W Fiber Laser Engraver Part 2

สนใจหรือติดต่อสอบถาม โทร
082-972-9329 (จิมมี่)
083-256-5981 (โกมินทร์)
E-mail : [email protected]
รูปภาพของปุ่มลิงค์ไปยัง LINE ของ Sale CNC

ดาวน์โหลดซอฟต์แวร์ และคู่มือการใช้งาน



ดาวน์โหลดโปรแกรม EZCad  คลิกที่นี่

คู่มือการใช้งาน คลิกที่นี่

การใช้งานโปรแกรม EZCad สำหรับเครื่อง CNC Marking Engraving – Laser Fiber  คลิกที่นี่



การติดตั้งโปรแกรม EZCad



การใช้งานโปรแกรม EZCad  (Part1)

การใช้งานโปรแกรม EZCad  (Part2)



Fiber Marking Machine 20W Parameters

Materials Marking effect Filling speed (mm/s) power (%) Frequency
Aluminum oxide block Marking dark 0.01 300 50 250
Stainless steel block Marking white 0.01 100 40 80
Stainless steel block Marking dark Cross 0.05 1000 65 35
Foreign white copper sheet Marking white Cross 0.03 1000 100 50
Stainless steel block Marking deep, marking dark 0.05 500 80 20
Stainless steel block Marking deep, marking dark 0.01 200 40 80
Stainless steel block Marking deep, marking dark 0.01 200 40 80
Stainless steel block Marking dark 0.01 200 40 80
Stainless steel block Marking dark 0.01 220 40 80
White lampshade Marking dark 0.03 1200 90 25
Red button Marking white Cross 0.01 1300 65 35
White black lacquer bottons Marking white Cross 0.04 1000 65 35
Silver material Marking white Cross 0.05 1200 100 35
Stainless steel block Wire drawing 0.09 1000 70 35
Stainless steel block Wire drawing 0.12 1000 70 35
Stainless steel block Wire drawing 0.25 1000 70 35
Red copper Marking deep, marking white 0.02 100 100 20
Red copper Marking deep, marking white 0.02 1000 70 80
Red copper Marking deep, marking red 0.01 100 100 80
Red copper Marking deep, marking red 0.03 1200 65 25
White plastic pipes blace 0.03 1200 65 25
White background coating Blue lacquer Marking white 0.03 800 85 40
Circuit board Marking white 0.01 1000 95 32
Aluminum molds Marking white Cross 0.05 100 95 45
Brass Marking white Cross 0.05 1000 80 40
Black hard plsatic Marking white 0.05 1500-2000 60-75 25-45
Iron Marking white Cross 0.05 1000 55 35
The new laser housing Marking dark 0.01 100 100 20
Brass Marking deep, marking dark Cross 0.01 100 95 20
Aluminum Alloy Marking deep, marking dark Cross 0.01 200 100 30



Download Brochures



ดาวน์โหลดโบชัวร์ Download Brochures —-> คลิกที่นี่

Brochures CNC Fiber Engraving 20W
