Automatic Blower Feeder W600*H400
Straight feed 140, Rail, Bottom stand
The Blower Feeder W600 H400 is an automatic air-fed workpiece feeding system with a straight feed rail and a floor-standing base. It is designed for integration with sorting machines, feeders, and automation systems in industrial facilities.
🔧 Vibration Feeder W600×H400 (Straight Feed 140, Rail, Bottom Stand)
Automatic material feeder with a straight feeding system.
✅ Operational Description:
This model is designed to feed sheet-type materials such as envelopes, labels, and thin boxes. It utilizes a Vibration system to separate and continuously push materials one by one in a straight line.
📌 Workflow:
-
Material Placement in Feeder Tray:
Sheet materials are stacked horizontally. -
Vibration System Activation:
The vibration motor gently shakes the tray base, causing the materials to gradually move forward one sheet at a time. -
Straight Feed System:
A linear pusher mechanism at the end feeds the sheets sequentially into the next machine, such as a printer, laser cutter, or conveyor belt. -
Guide Rail System:
Guide rails steer the materials to travel straight, preventing deviation or tilting. -
Bottom Stand:
Provides stable support and elevates the unit to the correct height for integration into the production line.
⚙️ Summary of Technical Specifications
| Item | Details |
|---|---|
| Feeder Tray Dimensions | Width 600 mm x Height 400 mm |
| Feeding System | Vibration feeding + automatic straight pushing |
| Guidance System | Adjustable guide rails on both sides |
The Blower Feeder W600 H400 is engineered for continuous feeding and conveying of workpieces in production lines. It utilizes an air blowing system in conjunction with a straight feed rail to ensure orderly movement of workpieces, minimize jamming, and enhance operational stability.
The unit features dimensions of W600 × H400 mm, making it suitable for installation in typical factory environments. It efficiently supports integration with workpiece sorters, vibratory feeders, dispensing machines, and other automated systems. The straight feed rail has a width of 140 mm and is adjustable to accommodate various types of components, including screws, nuts, metal parts, and plastic components.
The construction includes a robust Bottom Stand that minimizes vibration and offers adjustable leveling, ideal for continuous industrial operation. The Blower Feeder W600 H400 system reduces manual labor, increases production speed, and is well-suited for implementation in automation systems.
The Blower Feeder W600 H400 is recommended for factories seeking to improve workpiece feeding efficiency and requiring a system that can be customized to specific operational needs.
