Fiber Laser Power Supply Model FMC6000
- The FMC series represents high-power, continuous-wave multi-fiber laser products developed and manufactured by Beijing Reci Laser Technology Co., Ltd. Available in an average output power range from 4,000W to 15,000W, these units feature a modular design, high integration, excellent environmental stability, long service life, and maintenance-free operation.
- This product series is widely applicable in metal cutting, welding, surface treatment, 3D printing, and rapid prototyping. Its advantages stem from high average power, superior high-reflection resistance, and high electro-optic conversion efficiency. Notably, it offers exceptional cutting speeds and produces bright kerfs when processing thick metal sheets, providing a distinct advantage over comparable lasers on the market.
Direct from factory 14 days receive goods.
Specifications:
| Specification | Detail |
|---|---|
| Output Power (W) | 6000 |
| Center Wavelength (nm) | 1080±3 |
| Operating Mode | CW/Modulate |
| Max Modulation Frequency (kHz) | 5 |
| Power Stability (%) | <3 |
| Red Laser | Yes |
| Fiber Delivery Connector | QBH (Customizable) |
| Output Fiber Diameter (µm) | 100 (Customizable) |
| BPP (mm*mrad) | <5 |
| Cable Transmission Length (m) | 20 (Customizable) |
| Voltage (VAC) | 380 |
| Power Consumption (W) | 24000 |
| Control Mode | Ext. RS 232/Ext. AD/Hyper Terminal |
| Power Range (%) | 10 ~ 100 |
| Ambient Temperature (°C) | 5 ~ 40 |
| Ambient Humidity (%) | <70 |
| QBH Cooling Water Temperature (°C) | Room Temperature |
| Cooling Water Temperature (°C) | 25 |
| Dimensions WxHxD (mm³) | 880 x 1222 x 1041 |
| Weight (kg) | >400 |
Company Profile :
Manufacturer: Beijing Reci Laser Technology Co., Ltd.
