Description

Conveyor Belt PVC

Industrial Conveyor Systems – PVC Material

Standard Height (Non-Adjustable)

• PVC material conveyor belts for transporting items.
• Equipped with an electric motor for adjustable belt speed control.
• Facilitates easy material handling and operational setup.
• Standard height: 75 cm (non-adjustable).
• Product load capacity on conveyor: approximately 30 kg.

Polyvinylchloride (PVC) Properties

• PVC offers excellent resistance to high temperatures, tensile strength, and puncture/tear resistance.
• Exhibits good wear resistance.
• Provides good resistance to oils and is odor-resistant.
• PVC demonstrates high durability against abrasion.

[conveyor_img_link]

Product Examples

• Conveyor Belt PU 600×2500 mm
• Motor: 200W
• Speed: 16-25 m/min
• Includes adjustable leveling feet and free-running casters.

Product Examples

Motor with Inverter Speed Control

Motor speed ratio: 30-40 meters/minute. Additional cost: 7500 THB

• Conveyor Belt PVC 500x1000x750 mm
• Speed: 40 m/min. Adjustable leveling feet: 100 mm.
• Load capacity: 3 kg across the entire belt length.
• Price: 32,000 THB

• Conveyor Belt PVC 500x1500x750 mm
• Speed: 40 m/min. Adjustable leveling feet: 100 mm.
• Load capacity: 3 kg across the entire belt length.

• Conveyor Belt PU with Stainless Steel Frame: 400x1500x800 mm
• Speed: 8-13 m/min. Adjustable leveling feet: 100 mm.
• Load capacity: 30 kg across the entire belt length.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min. Adjustable leveling feet.
• Load capacity: 20 kg across the entire belt length.

• Conveyor Belt PU with Aluminum Profile Frame: 500×4500 mm
• Speed: 8-13 m/min. Adjustable leveling feet.
• Load capacity: 30 kg across the entire belt length.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×6000 mm
• Speed: 8-13 m/min. Adjustable leveling feet.
• Load capacity: 30 kg across the entire belt length.

• Conveyor Belt PU with 304 Stainless Steel Frame and Stainless Steel Table: 500×3000 mm
• Speed: 3-5 m/min. Adjustable leveling feet.
• Load capacity: 30 kg across the entire belt length.

• Conveyor Belt PU with 304 Stainless Steel Frame and Stainless Steel Table: 400×3000 mm
• Speed: 3-5 m/min. Adjustable leveling feet.
• Load capacity: 30 kg across the entire belt length.

• Conveyor Belt PU with 304 Stainless Steel Frame: 500×1500 mm
• Speed: 8-13 m/min. Adjustable leveling feet.
• Load capacity: 30 kg across the entire belt length.

• Steel Structure Stainless 304 Conveyor Solid

• Speed: 3-5 m/min. Adjustable leveling feet.
• Load capacity: 40 kg across the entire belt length.

• Conveyor Belt PVC 300x1500x750 mm
• Conveyor Belt PVC 300x1000x750 mm
• Conveyor Belt PVC 300x1200x300 mm
• Speed: 8-13 m/min
• Weight capacity: 2-3 kg.

•
• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min. Adjustable leveling feet.
• Load capacity: 30 kg across the entire belt length.

• Conveyor Belt with 304 Stainless Steel Mesh and 304 Stainless Steel Frame: 600×1000 mm
• Speed: 3-5 m/min. Adjustable leveling feet.
• Load capacity: 40 kg across the entire belt length.

Conveyor Belt PVC Speed Specifications

English Specifications

Thai Specifications

https://youtu.be/nlWc4jRPjM0?si=pLIe53J2EObnbE1w

Product Load Capacity on Conveyor: Approximately 30 kg

• Standard motor: 120W. Optional motors: 200W, 400W, 600W.

Differences Between PVC, PU, and Stainless Steel Conveyor Belts

• Materials and Properties

  • PVC (Polyvinyl Chloride)
    ✅ Flexible and offers moderate chemical resistance.
    ✅ More economical than PU and stainless steel.
    ✅ Suitable for general applications such as packaging or transporting materials free of oil and grease.
    ❌ Not resistant to high temperatures and may wear faster than PU.

  • PU (Polyurethane)
    ✅ Superior resistance to fats, oils, and chemicals compared to PVC.
    ✅ Smoother surface, ideal for food and pharmaceutical industries.
    ✅ Higher resistance to tearing and longer service life than PVC.
    ❌ Higher cost than PVC.

  • Stainless Steel
    ✅ High strength, resistant to impact and wear.
    ✅ Suitable for industries requiring high hygiene standards, such as food and beverage production.
    ✅ Resistant to high temperatures and chemicals.
    ❌ Higher cost and potentially heavier.

• Recommended Applications

  • PVC → General goods transport (e.g., packaging, electronics).
  • PU → Food and pharmaceutical industries, or applications involving contact with oil or grease.
  • Stainless Steel → Applications requiring high hygiene, or environments with high temperatures or humidity (e.g., food and beverage processing, heavy industry).
