Automatic Band Saw Machine
model VA plus – 33NC
🟡 Science Laboratory
Equipment in the Lab
🟡 Production Technology & Equipment
🟡 Product Parameter Configuration
| Model | VA plus – 33NC | VA – 33NC |
|---|---|---|
| Blade size | 34*1.1*4115 | |
| Diameter of saw roller | 450MM | |
| Cutting capacity | W: 330MM H: 330MM | |
| Maximum feeding length | 500MM | |
| Main motor | 4KW | |
| Blade speed (M/MIN) | 20 – 80 | 25 / 45 / 64 / 80 |
| Hydraulic motor | 0.75KW | |
| Oil tank capacity | 40L | |
| Cutting feeding way | Hydraulic stepless | |
| Cooling motor | 90W | |
| Water tank capacity | 40L | |
| Chip cleaning way | Chip conveyor | |
| Machine size | 2350x2220x1500MM | |
| Net weight | 2100KG | |
Standard Configuration Band Saw Machine
model VA – 33NC
🟡 Control Panel
- PLC and piano painting button
🟡 Power-off Protection
- More secure, more relieved
🟡 Hydraulic Clamping Cylinder
- Special treatment, longer service life
🟡 Steel Pipe Route
- Wiring aging prevention, longer service life
🟡 Narrow Vice Jaw Short Scrap
- Wear-proof sheet steel embedding in the vice jaw abrasion-proof jaw surface
🟡 Quick Drop Beam
- Vertical waterflow, accelerated cooling, higher cutting efficiency
🟡 Quenching Roulette
- Auto conterpoise design, reduce sawing vibration
🟡 Open Type Hydraulic Station
- Convenient maintenance and monitoring, accelerated heat dissipation
- Belt pulley
- Guide arm
Upgrade Configuration Band Saw Machine
model VA plus – 33NC
🟡 Intelligent Speed Regulation
- Automatic speed adjustment according to the material hardness
🟡 Dual System Electrical Control Cabinet
- Tidy wiring, convenient to maintain
🟡 Automatic Blade Tensioning
🟡 Chip Conveyor
- Chip conveyor, waste accumulation prevention
🟡 A Better Sawing Machine Needs Better Saw Blades
Naipusi
Cutting material :
- Mild steel (45#steel, A3=Q235, Q195, Q215)
- Structural section (Angle Iron, U beam, H beam, Channel steel)
- Cold rolled steel, Aluminum alloy, Magnesium alloy, Seamless pipe,
- Colour coated steel sheets
- High-carbon steel (Q255, Q275, Q345)
- 304 stainless steel, Copper, Aluminum
bT-BAISTTE
Cutting material : 201, 304 stainless steel, 20Cr, 40Cr, 20 manganese steel, Die steel(P20, H13), Ductile iron, 45CrMoAl Alloy steel, Forged steel, Graphitic cast iron.
V”anoch
Cutting material : Stainless iron(2Cr13), Red copper, 316, 316LStainless iron, Hot rolled steel, 42CrMoA (Good effect), Rail steel, High-speed steel, Excavator hammer drill(General material Cr12movTi), Ductile iron, Titanium alloy.
Ai.DEAL
Cutting material : H13 large steel plate, Titanium alloy, die steel(S136. 718), titanium alloy, titanium alloy etc.
