Description

Conveyor Belt PVC

(Adjustable Height)

Conveyor BC Height Adjustment Options:

1. 700 to 1000 mm (300mm adjustment range)
2. 750 to 1100 mm (350mm adjustment range)
3. 800 to 1150 mm (350mm adjustment range)
4. 900 to 1300 mm (400mm adjustment range)
5. 950 to 1400 mm (450mm adjustment range)
6. 1000 to 1500 mm (500mm adjustment range)

(Select one height adjustment level)

Adjustment Details:

• 75cm Base Height: 35 cm adjustment range
• 80cm Base Height: 35 cm adjustment range
• 85cm Base Height: 40 cm adjustment range
• 90cm Base Height: 40 cm adjustment range
• 95cm Base Height: 45 cm adjustment range
• 100cm Base Height: 50 cm adjustment range

(Select one adjustment level)

• PVC Conveyor Belt for material handling and transportation.
• Equipped with an electric motor for adjustable belt speed.
• Facilitates easy material transfer and item sorting; simple to install and operate.
• Standard machine height: 75 cm (fixed, non-adjustable).
• Product load capacity on conveyor: approximately 30 kg.

Polyvinylchloride (PVC) Properties:

• PVC offers good resistance to high temperatures, tensile strength, and cutting/puncture.
• Exhibits excellent wear resistance.
• Resistant to oils and odors.
• Durable and resistant to abrasion.

Example Configurations:

Inverter Motor with Speed Ratio Adjustment (30-40 meters/minute) – Additional Charge: 7500 Baht

• Conveyor Belt PVC: 500x1000x750 mm
• Speed: 40 m/min; Adjustable Legs: 100 mm height adjustment range
• Total Load Capacity: 3 Kg.
• Price: 32,000 Baht

• Conveyor Belt PVC: 500x1500x750 mm
• Speed: 40 m/min; Adjustable Legs: 100 mm height adjustment range
• Total Load Capacity: 3 Kg.

• Conveyor Belt PU with Stainless Steel Frame: 400x1500x800 mm
• Speed: 8-13 m/min; Adjustable Legs
• Total Load Capacity: 30 Kg.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min; Adjustable Legs
• Total Load Capacity: 20 Kg.

• Conveyor Belt PU with Aluminum Profile Frame: 500×4500 mm
• Speed: 8-13 m/min; Adjustable Legs
• Total Load Capacity: 30 Kg.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×6000 mm
• Speed: 8-13 m/min; Adjustable Legs
• Total Load Capacity: 30 Kg.

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table: 500×3000 mm
• Speed: 3-5 m/min; Adjustable Legs
• Total Load Capacity: 30 Kg.

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table: 400×3000 mm
• Speed: 3-5 m/min; Adjustable Legs
• Total Load Capacity: 30 Kg.

• Conveyor Belt PU with Stainless Steel 304 Frame: 500×1500 mm
• Speed: 8-13 m/min; Adjustable Legs
• Total Load Capacity: 30 Kg.

• Steel Structure Stainless 304 Conveyor Solid

• Speed: 3-5 m/min; Adjustable Legs
• Total Load Capacity: 40 Kg.

• Conveyor Belt PVC: 300x1500x750 mm
• Conveyor Belt PVC: 300x1000x750 mm
• Conveyor Belt PVC: 300x1200x300 mm
• Speed: 8-13 m/min
• Load Capacity: 2-3 kg.

•
• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min; Adjustable Legs
• Total Load Capacity: 30 Kg.

• Stainless Steel 304 Mesh Conveyor with Stainless Steel 304 Frame: 600×1000 mm
• Speed: 3-5 m/min; Adjustable Legs
• Total Load Capacity: 40 Kg.

PVC Conveyor Belt Speed Specifications

English Specifications

Thai Specifications

https://youtu.be/nlWc4jRPjM0?si=pLIe53J2EObnbE1w

Product load capacity on conveyor: approximately 30 kg

• Standard motor: 120W. Optional motors available: 200W, 400W, 600W.

Comparison of PVC, PU, and Stainless Steel Conveyor Belts

1. Materials and Properties

   • PVC (Polyvinyl Chloride)
     ✅ Flexible and offers moderate chemical resistance.
     ✅ More economical than PU and Stainless Steel.
     ✅ Suitable for general applications such as packaging or transporting materials without oil and grease.
     ❌ Not resistant to high temperatures and may wear faster than PU.
   • PU (Polyurethane)
     ✅ Superior resistance to fats, oils, and chemicals compared to PVC.
     ✅ Smoother surface, ideal for food and pharmaceutical industries.
     ✅ Higher tear strength and longer lifespan than PVC.
     ❌ Higher cost than PVC.
   • Stainless Steel
     ✅ High strength, resistant to impact and wear.
     ✅ Suitable for industries requiring high hygiene standards, such as food and beverage production.
     ✅ Resistant to high temperatures and chemicals.
     ❌ High cost and potentially heavier.

2. Suitable Applications

   • PVC → General goods transportation, such as packaging and electronics.
   • PU → Food and pharmaceutical industries, and applications involving contact with oil or grease.
   • Stainless Steel → Applications requiring high hygiene, or environments with high heat or humidity, such as food processing plants, beverage facilities, and heavy industries.
