A. Nominal Diameter (mm)
Example: 16-5 = 16mm diameter, 5 lead
12-4 16-4 16-5 16-10 20-4 20-5 25-4 25-5 32-4 32-5 32-10 40-5 40-10

C. Accuracy Grade
Roll = 23–52 micron-m/300mm, Ground = 12–16 micron-m/300mm
Roll Ground

D. Thread Right or Left
Right Left

E. End Machining One End (mm)
0 for no machining

F. Total Screw Length (mm)

G. End Machining The Other End (mm)
0 for no machining

H. Nut Type
Single Double

Calculate Price / คำนวณราคา
