Description

Conveyor Belt – PVC Type

(Adjustable Height)

Conveyor BC – Selectable Height Adjustment:

1. 700 to 1000 mm (300mm adjustment range)
2. 750 to 1100 mm (350mm adjustment range)
3. 800 to 1150 mm (350mm adjustment range)
4. 900 to 1300 mm (400mm adjustment range)
5. 950 to 1400 mm (450mm adjustment range)
6. 1000 to 1500 mm (500mm adjustment range)

Select one height adjustment level.

Height Adjustment Specifications:

• BC Series: 75cm base height, 35cm adjustable range
• BC Series: 80cm base height, 35cm adjustable range
• BC Series: 85cm base height, 40cm adjustable range
• BC Series: 90cm base height, 40cm adjustable range
• BC Series: 95cm base height, 45cm adjustable range
• BC Series: 100cm base height, 50cm adjustable range

Select one height adjustment level.

• PVC Conveyor Belt for material handling and transport.
• Electric motor driven with adjustable speed control.
• Facilitates easy material transfer and conveying; simple installation and operation.
• Standard machine height: 75 cm (non-adjustable).
• Maximum product load on conveyor: approximately 30 kg.

Polyvinyl Chloride (PVC) Properties:

• PVC exhibits excellent resistance to high temperatures, tensile strength, and is highly resistant to cuts and punctures.
• Features superior wear resistance.
• Demonstrates good resistance to oils and odors.
• Offers robust durability against abrasion.

Example Products:

Optional Inverter Motor with Speed Control: 30-40 meters/minute. Additional Cost: 7,500 THB

• Conveyor Belt PVC: 500x1000x750 mm
• Speed: 40 m/min; Adjustable Height Legs: 100 mm
• Maximum load capacity: 3 kg across the entire belt.
• Price: 32,000 THB

• Conveyor Belt PVC: 500x1500x750 mm
• Speed: 40 m/min; Adjustable Height Legs: 100 mm
• Maximum load capacity: 3 kg across the entire belt.

• Conveyor Belt PU with Stainless Steel Frame: 400x1500x800 mm
• Speed: 8-13 m/min; Adjustable Height Legs: 100 mm
• Maximum load capacity: 30 kg across the entire belt.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min; Adjustable Legs
• Maximum load capacity: 20 kg across the entire belt.

• Conveyor Belt PU with Aluminum Profile Frame: 500×4500 mm
• Speed: 8-13 m/min; Adjustable Legs
• Maximum load capacity: 30 kg across the entire belt.

• Conveyor Belt PVC with Aluminum Profile Frame: 300×6000 mm
• Speed: 8-13 m/min; Adjustable Legs
• Maximum load capacity: 30 kg across the entire belt.

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table: 500×3000 mm
• Speed: 3-5 m/min; Adjustable Legs
• Maximum load capacity: 30 kg across the entire belt.

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table: 400×3000 mm
• Speed: 3-5 m/min; Adjustable Legs
• Maximum load capacity: 30 kg across the entire belt.

• Conveyor Belt PU with Stainless Steel 304 Frame: 500×1500 mm
• Speed: 8-13 m/min; Adjustable Legs
• Maximum load capacity: 30 kg across the entire belt.

• Steel Structure Stainless 304 Conveyor Solid

• Speed: 3-5 m/min; Adjustable Legs
• Maximum load capacity: 40 kg across the entire belt.

• Conveyor Belt PVC: 300x1500x750 mm
• Conveyor Belt PVC: 300x1000x750 mm
• Conveyor Belt PVC: 300x1200x300 mm
• Speed: 8-13 m/min
• Weight Capacity: 2-3 kg

•
• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed: 8-13 m/min; Adjustable Legs
• Maximum load capacity: 30 kg across the entire belt.

• Conveyor Belt with Stainless Steel 304 Mesh and Stainless Steel 304 Frame: 600×1000 mm
• Speed: 3-5 m/min; Adjustable Legs
• Maximum load capacity: 40 kg across the entire belt.

Speed Specifications for Conveyor Belt PVC

https://youtu.be/nlWc4jRPjM0?si=pLIe53J2EObnbE1w

Product load capacity on conveyor: approximately 30 kg

• Standard motor: 120W. Optional motors available: 200W, 400W, 600W.

Differences between PVC, PU, and Stainless Steel Conveyor Belts:

1. Materials and Properties

   • PVC (Polyvinyl Chloride)
     ✅ Flexible and offers moderate chemical resistance.
     ✅ More economical than PU and stainless steel.
     ✅ Suitable for general applications such as packaging or transporting materials free of oils and fats.
     ❌ Not resistant to high temperatures and may wear faster than PU.
   • PU (Polyurethane)
     ✅ Superior resistance to oils, fats, and chemicals compared to PVC.
     ✅ Smoother surface, ideal for food and pharmaceutical industries.
     ✅ Higher tensile strength and longer lifespan than PVC.
     ❌ Higher cost than PVC.
   • Stainless Steel
     ✅ High strength, resistant to impact and wear.
     ✅ Suitable for industries requiring high sanitation levels, such as food and beverage production.
     ✅ Resistant to high temperatures and chemicals.
     ❌ Higher cost and potentially heavier weight.

2. Suitable Applications

   • PVC → General goods transport, such as packaging and electronics.
   • PU → Food and pharmaceutical industries, or applications involving contact with oils or fats.
   • Stainless Steel → Applications demanding high hygiene standards or operating in high-temperature or high-humidity environments, such as food and beverage processing plants, and heavy industrial sectors.
