Industrial Chiller CW-3000
Used for cooling CNC machines and fiber lasers. Easy to operate, preventing overheating during operation.
Water Cooling Systems for Industrial Applications
Industrial Water Chillers for Factories
- In tropical climates with year-round high temperatures, industrial equipment and electronics are susceptible to overheating when operating. Exceeding operational temperature limits can lead to component failure, reduced efficiency, and in severe cases, fire hazards. Just as elevated body temperature impacts human performance, excessive heat in machinery impairs its functionality. Therefore, maintaining optimal operating temperatures through proper machine maintenance and the use of a Chiller is crucial.
- A chiller is a refrigeration unit designed to produce cooling. Available in various sizes, its primary function is to generate cooling, reduce temperature, and dissipate heat, typically using water as the heat transfer medium. Chillers are widely employed in industrial settings to manage machine heat loads, extend equipment lifespan, and ensure consistent operational performance.
Specifications
✔️ Model: CW-3000
✔️ Voltage: AC 1P 220V
✔️ Frequency: 50/60Hz
✔️ Current: 0.45A
✔️ Radiating capacity: 50W/ C
✔️ Tank capacity: 9L
✔️ Inlet & Outlet: External Φ10mm brass connector
✔️ Max. lift: 10M
✔️ Max. flow: 10L/min
✔️ Protection: Flow alarm
✔️ Net weight: 9.5kgs.
✔️ Gross weight: 12kgs.
✔️ Dimension: 27x47x37cm
✔️ Packing dimension: 39x59x48cm
Download details of all models of Chiller English – chick here
Chiller Model Comparison
| Model | Voltage/Frequency | Pump Power | Current | Cooling Capacity | Pressure | Flow Rate | Dual temperature and Dual Control |
|---|---|---|---|---|---|---|---|
| JL/CW-3000 | 220V/50HZ | 80W | 0.35A | – | 9M | 11 L/min | not support |
| JL/CW-5000 | 220V/50HZ | 750W | 3.5A | 1750W | 9M | 11 L/min | support/not support |
| JL-5200 | 220V/50HZ | 770W | 3.6A | 1750W | 12M | 19 L/min | support/not support |
| JL-6000 | 220V/50HZ | 1320W | 7A | 2850W | 20M | 3.3 m3/h | support |
| JLFL/FL-1000 | 220V/50HZ | 3050W | 14A | 3650W | 39M | 2 m3/h | support |
| JLFL-1500 | 220V/50HZ | 3500W | 17A | 5520W | 47M | 2 m3/h | support |
| JLFL-2000 | 220V/380V 50HZ | 4300W | 11A/19A | 7100W | 47M | 2 m3/h | support |
