About connection method:
- The linear actuator motor’s plug is designed for use with our controller. If using a third-party controller, the connector may need to be disconnected. The unit features two wires for polarity control; reversing these connections will reverse the operational direction (extend/retract). An external switch can be integrated for manual control of extension and retraction.
- Minimum mounting dimensions (distance between mounting holes when the push rod is fully retracted): L = S + 175mm, where S is the retracted stroke length.
- Maximum mounting dimensions (distance between mounting holes when the push rod is fully extended): 2 * S + 175mm, where S is the extended stroke length.
- The linear actuator motor utilizes two wires (positive and negative) for telescopic (lifting/lowering) control.
- Note: Higher speeds are associated with lower thrust, and slower speeds with higher thrust.
