About connection method:
- The linear actuator motor’s plug is supplied with our controller. If a compatible controller is not used, the connector can be cut off. The unit has two wires: positive and negative. Reversing the polarity controls extension and retraction. A polarity reversal switch can be added for manual control of telescopic movement.
- Minimum mounting dimensions (push rod fully retracted, spacing between mounting holes): L = S + 175mm.
- Maximum mounting dimensions (push rod fully extended, spacing between mounting holes): 2 * S + 175mm.
- The linear actuator motor has 2 wires (positive and negative) for controlling telescopic extension and retraction (lifting).
- Higher speed is achieved at the cost of reduced thrust; conversely, lower speed results in greater thrust.
