About connection method:
- The motor’s plug connector is designed for integration with our dedicated controllers. If a supporting controller is not utilized, the connector can be severed. The two exposed wires represent positive and negative terminals. Reversing their polarity will invert the directional control of extension and retraction. An optional positive and negative switch can be incorporated for independent telescopic control.
- Minimum mounting dimension (with push rod fully retracted, distance between mounting holes): L = S + 175mm.
- Maximum mounting dimension (with push rod fully extended, distance between mounting holes): 2 * S + 175mm.
- The actuator motor features two wires (positive and negative) for controlling extension and retraction (lifting).
- Higher speed results in lower thrust; conversely, lower speed yields greater thrust.
