About connection method:
- The provided motor plug is designed for integration with our proprietary controller. If an alternative controller is employed, the connector may require modification. The unit features two lines for power input: positive and negative. Reversing the polarity of these connections will reverse the motor’s motion (telescoping and retraction). An optional polarity-reversing switch can be added for independent bidirectional control.
- Minimum mounting dimensions (distance between mounting holes when the push rod is fully retracted): L = S + 175mm, where ‘S’ represents the stroke length.
- Maximum installation dimensions (distance between mounting holes when the push rod is fully extended): 2 * S + 175mm.
- The motor operates with two lines (positive and negative) for bidirectional telescopic control (actuation/lifting).
- Operating speed is inversely proportional to thrust; higher speeds result in lower thrust, and lower speeds result in higher thrust.
