About connection method:
- The linear actuator motor plug is supplied with our controller. If used without a supporting controller, the connector can be cut off. The remaining two wires function as positive and negative terminals for control. Reversing the polarity will reverse the direction of extension and retraction. A simple positive/negative switch can be integrated for manual control of telescoping action.
- Minimum Mounting Dimensions: The distance between mounting holes when the push rod is fully retracted is denoted as L = S + 175mm, where S represents the stroke length.
- Maximum Installation Dimensions: The distance between mounting holes when the push rod is fully extended is 2 * S + 175mm.
- The linear actuator motor utilizes two wires (positive and negative) for controlling the extension and retraction (lifting) motion.
- Note: Higher speed operation results in lower thrust, and conversely, slower operation yields greater thrust.
