About connection method:
- The motor plug is equipped with a dedicated controller. If no controller is used, the plug can be cut. The two wires represent positive and negative terminals. Reversing polarity controls the extension and retraction of the actuator. A simple polarity reversing switch can be used for telescopic control.
- Minimum mounting dimension (when the push rod is fully retracted, distance between mounting holes): L = S + 175mm.
- Maximum mounting dimension (when the push rod is fully extended, distance between mounting holes): 2 * S + 175mm.
- The motor has two wires (positive and negative) for controlling extension/retraction (lifting/lowering).
- Higher speed results in lower thrust; conversely, lower speed results in greater thrust.
