Description

Fiber Laser Power Supply Model FSC4000

fsc4000

The FSC series represents a high-power, continuous wave fiber laser, developed and manufactured by Beijing Reci Laser Technology Co., Ltd. With an average power exceeding 4,000 W, it utilizes a single resonant cavity and single-mode design. This configuration effectively addresses limitations such as transverse mode instability (TMI), stimulated Raman scattering (SRS), and suboptimal beam quality.
This product line is extensively applicable in precision cutting, welding, surface treatment, 3D printing, and rapid prototyping. Its high average power, multi-reflection protection, high optical quality, and efficiency make it particularly advantageous for cutting thick metal sheets, offering superior performance compared to similar lasers in the market due to its excellent cutting quality and brightness.

Direct from factory, 14 days delivery.

Specifications:

Specification	Details
Output Power (W)	4000
Central Wavelength (nm)	1080±3
Operating Mode	CW/Modulate
Max Modulation Frequency (kHz)	100
Output Power Stability (%)	<3
Red Laser	Yes
Fiber Output Connector	QBH
Fiber Output Diameter (µm)	100
BPP (mm*mrad)	<3.4
Cable Length (m)	15 (Customizable)
Voltage (VAC)	380
Power Consumption (W)	16000
Control Mode	Ext. RS 232/Ext. AD/Hyper Terminal
Power Range (%)	10 ~ 100
Ambient Temperature (°C)	5 ~ 40
Ambient Humidity (%)	<70
QBH Cooling Water Temperature (°C)	Room Temperature
QBH Cooling Water Flow (L/min)	1.5 ~ 2.5
Cooling Water Temperature (°C)	25
Water Cooling Flow (L/min)	>55
Dimensions WxHxD (mm³)	483 x 244 x 989
Weight (kg)	<120
