Fiber Laser Cutting Machine Nozzles

Single-Layer and Double-Layer Cutting Nozzles

Nozzle Type	Application	Assist Gas	Size
Single Layer	For cutting Stainless Steel, Aluminum, etc.	Nitrogen	1.4 – 3.0 mm
Double Layer	For cutting Carbon Steel	Oxygen	1.5 – 3.0 mm

1. Single-Layer Nozzles: Designed for cutting stainless steel and aluminum. Utilizing nitrogen as an assist gas, these nozzles, with sizes ranging from 1.4-3.0 mm, ensure efficient cutting performance.

2. Double-Layer Nozzles: Primarily used for cutting carbon steel. Employing oxygen as an assist gas, these double-layer nozzles, available in sizes from 1.5-3.0 mm, deliver effective cutting results.

Laser Nozzle Sizing

Laser Nozzle Dimensions
