Description

B-1390 CNC Laser Engraving Cutting Machine 1300x900mm – 80W

Download Brochures: Click Here

Manuals:

• Controller Components and Basic Operation Manual: Click Here
• English User Manual: Click Here
• AutoLaser Software Installation Files Version 2.5.2: Click Here
• AutoLaser Software Installation Guide Version 2.5.2: Click Here

Machine Specifications:

• Model: B-1390
• Cutting Area: 1300 x 900 mm
• Laser Power: 80W (Optional: 100W, 120W)
• Cutting Speed: 0-64000 mm/min (options)
• Accuracy: 0.01 mm
• Power Consumption: AC 220V
• Operating Temperature: 0°C – 45°C
• Supported Graphics: BMP, GIF, JPEG, PCX, TGA, TIFF, PLT, CDR, DWG, DXF
• Dimensions: 1850 x 1500 x 1000 mm
• Weight: 340 kg

Material Cutting Depth:

Free Inclusions: 1. Water Cooling System 2. Ventilation Fan 3. Water Pump

––––––––––– SAMPLE CUT/ENGRAVE –––––––––––

WOOD GROUP

ACRYLIC & PLASTIC GROUP

FABRIC & LEATHER GROUP

MARBLE & STONE

Applicable Materials

This CO₂ laser machine is suitable for non-metal materials, including:

• Acrylic / Plastics / PMMA sheets
• Wood / MDF / Plywood / Fancy wood
• Leather / Fabric / Sewing applications / Decorating
• Bamboo / Fiberboard / Craft materials
• Other non-metal materials (thickness and laser power dependent)

For cutting metals or thicker materials, a fiber laser or higher power laser source may be required.

Recommended Applications

• Ideal for sign making, acrylic fabrication, decoration, and wood/leather crafts requiring medium-to-large sized cutting and engraving areas.
• Suited for small to medium-sized factories or production shops needing precision and high production speed.
• Recommended for users upgrading from smaller machines or requiring increased laser power for thicker materials.
• This machine is also suitable for processing PVC conveyor belts or other mid-sized material processing applications, offering sufficient table space (1300x900mm) for multi-piece production.

AutoLaser Software Demonstration:

CO₂ Laser Tube and Chiller Operation

Recommendations

• Verify the maximum material thickness the machine can cut for your specific products (specifications may range from 0-20mm or 0-30mm depending on the material).
• Ensure your facility’s electrical supply (AC 220V) and ventilation systems are adequate.
• Confirm after-sales support, including installation, training, and maintenance services, as the machine is substantial (approx. 300-400 kg) and has numerous operating parameters.
• Inquire about warranty conditions and spare parts availability, particularly for the laser tube which has a limited lifespan.
• Plan the installation space, considering machine dimensions, ventilation, cooling systems, wiring pathways, and service access.
