Automatic Liquid Packaging Machine
Maximum film width: 20cm, Maximum bag length: 17cm
Sealing: 3-side seal
| Product Name: Automatic Liquid Packaging Machine System |
| Packaging Volume: 2-50 g (varies with material) |
| Weight: Approx. 60 KG |
| Speed: 0-25 packs/minute (dependent on product) |
| Electrical: 220V |
| Machine Dimensions: 42 x 50 x 145 CM |
| Construction: Stainless steel, rust-proof |
| Control System: LCD Display / Stepper Motor / Magnetic / Color Mark Positioning / Anti-Clamping |
| Application Suitability: All types of liquid products without solids or pulp. |
| Note: Machine dimensions and weight are approximate reference values only. |
Film Material Pricing:
PE/PET Film = 1 KG = 260 THB | Minimum Order: 30 KG | Total: 7,800 THB
VMPET/PE Film = 1 KG = 220 THB | Minimum Order: 30 KG | Total: 6,600 THB
Film Roll and Packaged Bag Specifications:
| Width (Before Packaging) | Width (After Packaging) | Length (After Packaging) |
|---|---|---|
| 6 cm | 3.0 cm | 2-16 cm |
| 7 cm | 3.5 cm | 2-16 cm |
| 8 cm | 4.0 cm | 2-16 cm |
| 9 cm | 4.5 cm | 2-16 cm |
| 10 cm | 5.0 cm | 2-16 cm |
| 12 cm | 6.0 cm | 2-16 cm |
| 12.5 cm | 6.25 cm | 2-16 cm |
| 14 cm | 7.0 cm | 2-16 cm |
| 16 cm | 8.0 cm | 2-16 cm |
| 18 cm | 9.0 cm | 2-16 cm |
| 20.0 cm | 10.0 cm | 2-16 cm |
| Film Width (Before Packaging): | Refers to the width of the film or pre-made pouch prior to the packaging process. | |
| Film Width (After Packaging): | The film is folded in half and sealed. For example, a 10 cm film width will result in a 5 cm wide sealed package. | |
| Length (After Packaging, Adjustable): | The length of the film is cut to size, allowing for adjustable packaging lengths from 2 cm to 16 cm to suit product dimensions. | |
| Film Definition: | Refers to the material (e.g., plastic film, pouches) used for wrapping or packaging the product. | |
Example Operation Videos:
